The versatility of SF6 circuit breaker technology allows it to be deployed in two primary switchgear architectures: Air-Insulated Switchgear (AIS) and Gas-Insulated Switchgear (GIS). In AIS, the breaker is a standalone apparatus with external ceramic or composite insulators, connected via open busbars. In GIS, the breaker is one module within a sealed metal-enclosed system where all live parts are insulated by SF6 gas. The China Electrical Equipment Supply Chain Platform provides expert guidance on this fundamental choice. We help clients weigh factors such as site space constraints (GIS offers a footprint as small as 10% of AIS), environmental conditions (GIS is ideal for polluted, coastal, or seismic areas), total installed cost, and maintenance philosophy. Our platform supplies SF6 breakers designed for both applications. For a compact urban substation expansion where land was prohibitively expensive, we advocated for a 145kV GIS solution. We supplied the complete GIS bays, which included the SF6 circuit breakers, disconnectors, earthing switches, and busbars, all from a single manufacturer to ensure perfect compatibility. For a rural transmission line tap, a cost-effective AIS solution with standalone SF6 breakers was the optimal choice. Our unbiased analysis ensures the technology selection aligns with your project's unique drivers. To receive a comparative analysis of AIS versus GIS solutions featuring SF6 circuit breakers for your specific site parameters, please contact our application engineering team.
